DANCO VALVE SAFETY RELIEF P/N BCMBB05SAA SIZE 1/4"
SIZE 1/4" BODY MATL B61 SERVICE AIR TEMP 425F CAPACITY 158.8 SCFM ID NO. BCMBB05SAA DWG NO. D1400-946 REV.A SERIAL NO. 41372 SET PRESS 46 ACCUM PRESS 55
SET PRESS RANGE 45/75 RESEAT PRESS 37 INLET LOSS MAX 2.25 BACK PRESS MAX 4.6
NSN 4820011276051
| Name | Value |
| FLOW CONTROL DEVICE | DISK |
| BONNET TYPE | INSIDE SPRING |
| BONNET ATTACHMENT METHOD | BOLTED |
| END ITEM IDENTIFICATION | LOS ANGELES CLASS SSN(688) |
| CONNECTION STYLE | SOCKET WITH BRAZING RING ALL ENDS |
| CONNECTION TYPE | UNTHREADED INTERNAL PIPE ALL ENDS |
| ADJUSTABLE PRESSURE RANGE | +45.0 TO 55.0 POUNDS PER SQUARE INCH |
| OPERATING PRESSURE | 400.0 POUNDS PER SQUARE INCH (PSI) MAXIMUM SINGLE RESPONSE |
| MATERIAL | COPPER ALLOY BODY |
| MATERIAL DOCUMENT AND CLASSIFICATION | QQ-C-390,ALLOY D4/D/ FED SPEC SINGLE MATERIAL RESPONSE BODY |
Call or email for a price
